Using Sonoff mini R2 without neutral wire sonoffmini noneutral electronicscreators

Using Sonoff mini R2 without neutral wire sonoffmini noneutral electronicscreators

Видео: Using Sonoff mini R2 without neutral wire sonoffmini noneutral electronicscreators

RuTube

Умный Жилищный Комплекс

Опубликовано: 04.02.2024 | Продолжительность: 00:17:13

I found a way to install a sonoff mini without a neutral wire behind the light switch. Unlike my previous sonoff hack this requires no soldering. its a very simple experimental circuit that I think requires further investigation. what do you think bigclivedotcom 00:00 Intro 01:52 Demonstrating the circuit working without neutral 02:30 Circuit diagram of sonoff mini no neutral operation 02:49 Building the basic no solder version of the circuit 07:56 Wire everything up to power up and test the circuit 10:14 Putting the Sonoff mini behind the light switch box 11:22 Adding short circuit overcurrent protection inrush current limiting 12:19 Add some flexible wires and heat shrink tubing to make a better job of it 12:56 Using an old-style incandescent light bulb as a current limiter to safely test your circuit 14:42 Dont let the magic smoke escape from your circuit 15:15 Explanation of how the circuit works without a neutral wire,

#

Категория видео: Обучение
